4920-00-006-5168

Find complete technical information, availability, and procurement data for: 4920-00-006-5168
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 4920-00-006-5168 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Maintenance and Repair Shop Equipment

Federal Supply Classification

4920 Aircraft Maintenance and Repair Shop Specialized Equipment

National Stock Number

4920-00-006-5168

Assigment Date

06/23/1972 (54 years ago)

Height: 1.500 inches, Width: 3.000 inches

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

End Item Identification: F-15 acft
Nominal Overall Length: 4.000 inches
Nominal Overall Width: 3.000 inches
Nominal Overall Height: 1.500 inches
Special Features: Consists of a threaded adapter with dial indicator; company item name-fixture control valve position
Functional Description: Used to replace the external master control valve retainer on the aileron actuator during testing
Reference Data and Literature: Serd number 0560

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 4920-00-006-5168?

The FSCG of the NSN 4920-00-006-5168 is 4920

Does NSN 4920-00-006-5168 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 4920-00-006-5168 contain precious materials?

Item does not contain precious metal.

Does NSN 4920-00-006-5168 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 4920-00-006-5168 was assigned to the Federal Catalog?

It was assigned 54 years ago, on Fri, Jun 23, 1972

What is the nominal length of nsn 4920-00-006-5168?

4.000 inches
