A-0186-1

View detailed technical data, stock status, and sourcing information for: A-0186-1
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for part A-0186-1 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5950 Coils and Transformers

National Stock Number

5950-01-192-3148

Item Name Code

06338

Assigment Date

10/19/1984 (41 years ago)

An item consisting of a partial turn as one or more turns of wire or other conductive material which constitutes one continuous untapped winding. It may be wound or formed in other than a circular manner and may be self-supporting, requiring no coil form. It is specifically designed to furnish inductive reactance in a circuit carrying radio frequency current ranging from 20 kilohertz (kilocycles) and above. It may include tuning devices, integral resistors and capacitors; however, excludes:filter (as modified). The coil has only two electrical terminals. For items having tapped winding or more than one winding - see transformer, radio frequency. For coils wound on resistors, which are designed to be inserted in the circuit of a radio frequency stage to suppress high frequency parasitic oscillations, see suppressor, parasitic.

open inclosure type, terminal single group mounting method, air wound single component coil form type, not established reliability indicator, 4 single component single winding turn quantity

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Reliability Indicator: not established
Turn Quantity: 4 single component single winding
Coil Form Type: air wound single component
Inclosure Type: open
Mounting Method: terminal single group
Rating Method: winding turns single component single winding
Winding Conductor Size: 0.03196 inches american wire gage single component single winding
Terminal Type And Quantity: 2 wire lead

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
A-0186-1	Radio Frequency Coil
A0186-001	Radio Frequency Coil

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5950-01-192-3148?

The FSCG of the NSN 5950-01-192-3148 is 5950

Does the NSN 5950-01-192-3148 have a Schedule B code assigned?

Yes, the Schedule B code is 8504500000

Does NSN 5950-01-192-3148 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5950-01-192-3148 contain precious materials?

Item does not contain precious metal.

Does NSN 5950-01-192-3148 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 5950-01-192-3148 was assigned to the Federal Catalog?

It was assigned 41 years ago, on Fri, Oct 19, 1984
