F3C10288-2

View detailed technical data, stock status, and sourcing information for: F3C10288-2
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for part F3C10288-2 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Valves

Federal Supply Classification

4820 Nonpowered Valves

National Stock Number

4820-01-156-5889

Item Name Code

36944

Assigment Date

06/22/1983 (43 years ago)

An item usually metallic, threaded or unthreaded, used for securing to or positioning into a mating part. It is designed to be used in a globe, relief, regulator valve and the like as a means of controlling the flow of liquids or gases in a given system. One end may have an integral disk or be designed to accommodate a metallic or nonmetallic disk. The other end is designed for a handwheel, lever, spring, diaphragm and the like for nonpowered operation or to accommodate a gear, solenoid, air motor and the like for powered operation. The handwheel and/or disk may be furnished with the item. Excludes:stem, faucet; and stem, needle valve.

4820-01-156-5889, valve piston

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
F2B10242	Valve Piston
F2B10242-4MF	Valve Piston
F3C10089 ITEM 2	Valve Piston
F3C10288-2	Valve Piston
F3C10321 ITEM 2	Valve Piston

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 4820-01-156-5889?

The FSCG of the NSN 4820-01-156-5889 is 4820

Does the NSN 4820-01-156-5889 have a Schedule B code assigned?

Yes, the Schedule B code is 8481909090

Does NSN 4820-01-156-5889 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 4820-01-156-5889 contain precious materials?

Item does not contain precious metal.

Does NSN 4820-01-156-5889 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 4820-01-156-5889 was assigned to the Federal Catalog?

It was assigned 43 years ago, on Wed, Jun 22, 1983
