5930-00-713-5317

Find complete technical information, availability, and procurement data for: 5930-00-713-5317
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5930-00-713-5317 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5930 Switches

National Stock Number

5930-00-713-5317

Item Name Code

00206

Assigment Date

01/01/1963 (63 years ago)

A switch which is actuated by changes in pressure of any gas or liquid or by changes in a vacuum acting upon its sensing element. Excludes:baroswitch; switch,pressure-thermostatic; and switch,sensitive.

5.125 inches nominal overall height, gage pressure switch type, 5.188 inches nominal overall length, inlet connection mounting method, 5.000 inches nominal overall width

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Overall Length: 5.188 inches nominal
Overall Height: 5.125 inches nominal
Overall Width: 5.000 inches nominal
Pressure Switch Type: gage
Mounting Method: inlet connection
Thread Quantity Per Inch: 16 all pressure connection
Nominal Thread Size: 0.375 inches single pressure connection
Nonpile-Up Contact Arrangement: 1 pole, double throw, both positions maintained
Terminal Type: screw
Contact Adjustability: actuation point not adjustable
Special Features: 5 psi to 150 psi operating pressure difference range
Thread Series Designator: npt all pressure connection

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
2600-0711	Pressure Switch
4400D2056-2	Pressure Switch

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5930-00-713-5317?

The FSCG of the NSN 5930-00-713-5317 is 5930

Does the NSN 5930-00-713-5317 have a Schedule B code assigned?

Yes, the Schedule B code is 8536509065

Does NSN 5930-00-713-5317 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5930-00-713-5317 contain precious materials?

Precious metal content is unknown

Does NSN 5930-00-713-5317 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 5930-00-713-5317 was assigned to the Federal Catalog?

It was assigned 63 years ago, on Tue, Jan 1, 1963
