5305-00-274-2197

Find complete technical information, availability, and procurement data for: 5305-00-274-2197
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5305-00-274-2197 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Hardware and Abrasives

Federal Supply Classification

5305 Screws

National Stock Number

5305-00-274-2197

Item Name Code

06672

Assigment Date

01/01/1963 (63 years ago)

An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads.

2a thread class, right-hand thread direction, headless (setscrew) head style, 1.168 inches minimum and 1.208 inches maximum thread length, 1.740 inches minimum and 1.760 inches maximum fastener length

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Thread Class: 2a
Thread Direction: right-hand
Thread Length: 1.168 inches minimum and 1.208 inches maximum
Fastener Length: 1.740 inches minimum and 1.760 inches maximum
Head Style: headless (setscrew)
Point Style: flat
Internal Drive Style: cross recess type 1
Nominal Thread Diameter: 0.375 inches
Thread Quantity Per Inch: 24
Material: copper alloy 464 overall
Material Document And Classification: qq-b-637 fed spec single material response or qq-b-639 fed spec single material response overall
Thread Series Designator: unf

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
404108PC3	Setscrew

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5305-00-274-2197?

The FSCG of the NSN 5305-00-274-2197 is 5305

Does the NSN 5305-00-274-2197 have a Schedule B code assigned?

Yes, the Schedule B code is 7415338550

Does NSN 5305-00-274-2197 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5305-00-274-2197 contain precious materials?

Item does not contain precious metal.

Does NSN 5305-00-274-2197 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5305-00-274-2197 was assigned to the Federal Catalog?

It was assigned 63 years ago, on Tue, Jan 1, 1963
