955201-1C

View detailed technical data, stock status, and sourcing information for: 955201-1C
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for part 955201-1C to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electrical and Electronic Equipment Components

Federal Supply Classification

5905 Resistor

National Stock Number

5905-00-006-5343

Item Name Code

32068

Assigment Date

06/23/1972 (54 years ago)

An arrangement of multiple fixed resistive elements or discrete resistors permanently encased, encapsulated, or potted together, to form an inseparable unit. The resistive elements, consisting of a thin layer of conductive material deposited on or fused to an insulating base, usually are electrically connected to each other and may be arranged in any circuit configuration. Excludes:resistor, fixed (as modified); resistor assembly; resistor network, fixed-variable; and resistor set, matched.

Body Height: up to 0.200 inches

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Temperature Coefficient Of Resistance In Ppm Per Deg Celsius: -150.0 to 150.0
Electrical Resistance: 10.000 kilohms intermediate resistance value
Electrical Resistance: 20.500 kilohms
Resistance Tolerance In Percent: -2.000 to 2.000 each resistor
Ambient Temp In Degree Celsius At Full Rated Power: 70.0
Ambient Temp In Degree Celsius At Zero Percent Rated Power: 125.0
Temp Range Of Temp Coefficient In Deg Celsius: -55.0/+125.0
Inclosure Method: Encapsulated
Terminal Quantity: 14
Terminal Type: Pin
Reliability Indicator: Not established
Terminal Length: at lest 0.100 inches
Body Length: up to 0.760 inches
Body Width: up to 0.290 inches
Body Height: up to 0.200 inches
Schematic Diagram Designator: Series network
Power Dissipation Rating In Watts: 0.125 each resistor
Identical Value Resistor Quantity: 2 highest resistance value
Identical Value Resistor Quantity: 4 intermediate resistance value
Identical Value Resistor Quantity: 4 lowest resistance value
Style Designator: Dual inline

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
006-509-001	Film Fixed Resistor Network
955201-1C	Film Fixed Resistor Network

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5905-00-006-5343?

The FSCG of the NSN 5905-00-006-5343 is 5905

Does the NSN 5905-00-006-5343 have a Schedule B code assigned?

Yes, the Schedule B code is 8533100057

Does NSN 5905-00-006-5343 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5905-00-006-5343 contain precious materials?

Precious metal content is unknown

Does NSN 5905-00-006-5343 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5905-00-006-5343 was assigned to the Federal Catalog?

It was assigned 54 years ago, on Fri, Jun 23, 1972

What is the length of nsn 5905-00-006-5343?

up to 0.760 inches
