4130-01-475-2326

Find complete technical information, availability, and procurement data for: 4130-01-475-2326
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 4130-01-475-2326 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Refrigeration, Air Conditioning, and Air Circulating Equipment

Federal Supply Classification

4130 Refrigeration and Air Conditioning Components

National Stock Number

4130-01-475-2326

Item Name Code

11361

Assigment Date

05/25/2000 (26 years ago)

A nonmetallic circular item with an aperature, having a solid round cross-section. They are used primarily for sealing. For items with other than round cross section, see packing,preformed. For noncircular items with a round cross-section, see seal,nonmetallic round section and rubber,round section.

14.000 inches nominal overall depth, 36.000 inches nominal overall width, ac heater current type, 52.000 inches nominal overall height, ac fan motor current type

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Overall Depth: 14.000 inches nominal
Overall Height: 52.000 inches nominal
Overall Width: 36.000 inches nominal
Current Type: ac fan motor
Current Type: ac heater
Cooling Medium: chilled water
Operating Speed At Rated Capacity In Rpm: 1800.0
End Item Identification: fan coil unit
Coil Tube Quantity: 1
Tube Circuit Quantity: 24
Supply Connection Size: .625 in od
Return Connection Size: .625 in od
Case With Built-In Condensate Drain Pan: included
Fan Type: centrifugal
Fan Drive Type: direct
Nominal Capacity In Btu Per Hour: 22890.0 cooling and 22890.0 heating
Heater Wattage Rating In Kilowatts: 6.0
Voltage In Volts: 440.0 fan motor
Voltage In Volts: 440.0 heater
Phase: three fan motor
Phase: three heater
Special Features: mil-a-24775; reversable connections (lh/rh), high impact shock and vibration resistance, has lvp (low voltage protection) capability
Frequency In Hertz: 60.0 heater
Frequency In Hertz: 60.0 fan motor
Material: copper tube
Material: steel case

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
1344D00	Air Cooler Unit
FCU V4-6.0KW-LV P	Air Cooler Unit
FCU-V4-6.0KW-LVP	Air Cooler Unit

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 4130-01-475-2326?

The FSCG of the NSN 4130-01-475-2326 is 4130

Does NSN 4130-01-475-2326 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 4130-01-475-2326 contain precious materials?

Precious metal content is unknown

Does NSN 4130-01-475-2326 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 4130-01-475-2326 was assigned to the Federal Catalog?

It was assigned 26 years ago, on Thu, May 25, 2000
