5315-00-080-4739

Find complete technical information, availability, and procurement data for: 5315-00-080-4739
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5315-00-080-4739 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Hardware and Abrasives

Federal Supply Classification

5315 Pins, Machine Keys and Nails

National Stock Number

5315-00-080-4739

Item Name Code

08323

Assigment Date

01/01/1963 (63 years ago)

A headed fastening device having a solid cylindrical or tubular body with retaining ball or pinlike detent(s). The detent(s) is/are positioned and actuated by means of a spring, elastomer or plunger. Plunger may be operated by thumb, cam or other means. May be furnished with a pull ring, pull and/or lock ring, attaching ring or hook.

0.3075 inches minimum and 0.3105 inches maximum shank diameter, 2 detent quantity, 1.800 inches minimum and 1.820 inches maximum grip length, 0.423 inches minimum and 0.453 inches maximum head diameter, 1.187 inches maximum ring handle diameter

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Head Diameter: 0.423 inches minimum and 0.453 inches maximum
Shank Diameter: 0.3075 inches minimum and 0.3105 inches maximum
Ring Handle Diameter: 1.187 inches maximum
Detent Quantity: 2
Grip Length: 1.800 inches minimum and 1.820 inches maximum
Actuation Type: pull and push
Hardness Rating: 36.0 rockwell c minimum and 40.0 rockwell c maximum shank
Shoulder To Head End Distance: 0.562 inches maximum
Detent To Tapered End Distance: 0.359 inches maximum
Material: steel comp 4130 shank
Material Document And Classification: mil-s-6758 fed spec single material response shank
Material Document And Classification: qq-s-763 fed spec single material response detent
Surface Treatment: cadmium and chromate shank
Surface Treatment Document And Classification: qq-p-416,ty 2,cl 2 fed spec single treatment response shank
Style Designator: ring handle

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
801A5-18S	Quick Release Pin
BLDS5-18	Quick Release Pin
BLDS518	Quick Release Pin
QRD1A0518	Quick Release Pin

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5315-00-080-4739?

The FSCG of the NSN 5315-00-080-4739 is 5315

Does the NSN 5315-00-080-4739 have a Schedule B code assigned?

Yes, the Schedule B code is 7319409000

Does NSN 5315-00-080-4739 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5315-00-080-4739 contain precious materials?

Precious metal content is unknown

Does NSN 5315-00-080-4739 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5315-00-080-4739 was assigned to the Federal Catalog?

It was assigned 63 years ago, on Tue, Jan 1, 1963
