5340-00-068-0549
Find complete technical information, availability, and procurement data for: 5340-00-068-0549
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5340-00-068-0549 to receive an up to date pricing and availability quote by email.
A forked part, having transverse hole(s) or slot(s) in each arm (prong) to accommodate a bolt, pin, or the like, and having a connection facility opposite the fork. It is designed to be attached to a shaft, rod, turnbuckle or the like by welding, threading, and/or pinning. May include provisions for locking. See also yoke, universal joint and connector, rod end. For items specifically designed for aviation, see clevis, rod end, aviation.
right-hand rod connection thread direction, 1.360 inches minimum and 1.516 inches maximum shank length, 0.828 inches minimum and 0.922 inches maximum rod connection thread length, 0.375 inches minimum and 0.377 inches maximum hole diameter, 3a rod connection thread class
Product Characteristics
Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.
- Thread Class
- 3a rod connection
- Thread Direction
- right-hand rod connection
- Thread Length
- 0.828 inches minimum and 0.922 inches maximum rod connection
- Shank Length
- 1.360 inches minimum and 1.516 inches maximum
- Hole Diameter
- 0.375 inches minimum and 0.377 inches maximum
- Shank Diameter
- 0.306 inches minimum and 0.312 inches maximum
- Overall Width
- 0.628 inches minimum and 0.697 inches maximum
- End Radius
- 0.461 inches nominal
- Fork Span Width
- 0.312 inches minimum and 0.322 inches maximum
- Distance From Pivot Pinhole Center To Rod Connection End
- 3.157 inches minimum and 3.219 inches maximum
- Fork Arm Thickness
- 0.180 inches minimum and 0.192 inches maximum
- Fork Depth
- 0.875 inches nominal
- Nominal Thread Size
- 0.375 inches rod connection
- Material
- steel overall
- Surface Treatment
- cadmium overall
- Surface Treatment Document And Classification
- qq-p-416,type 2,class 3 fed spec single treatment response overall
- Style Designator
- clevis
- Thread Series Designator
- unf rod connection
Replaces National Stock Numbers
Below is a list of NSNs that have been officially superseded by this NSN:
| NSN | Name | Date |
|---|---|---|
| 5340-00-244-9229 | No Name Available | 06/01/1981 |
| 5340-00-244-9230 | No Name Available | 06/01/1981 |
Related Parts
This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:
| Part Number | Name |
|---|---|
| AN161-80RL | Rod End Clevis |
| MS21252-8RL | Rod End Clevis |
| NAS645-61RL | Rod End Clevis |
| NAS645-80RL | Rod End Clevis |
