5325-00-282-1883

Find complete technical information, availability, and procurement data for: 5325-00-282-1883
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5325-00-282-1883 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Hardware and Abrasives

Federal Supply Classification

5325 Fastening Devices

National Stock Number

5325-00-282-1883

Item Name Code

18421

Assigment Date

01/01/1963 (63 years ago)

A pinlike item designed to turn within and be held in place by an eyelet, turnlock fastener; ring, retaining; or the surface of the item it fastens. It is provided with either a cam slot, cam lead threads, or a hold for accommodating a pin. Securing is accomplished by mating with a lockspring, turnlock fastener or receptacle, turnlock fastener. It has either provisions to accommodate a knob or extension or has a head which has provisions to facilitate turning.

fillister wing turnlock stud head style, stud shank turnlock stud shank style, 0.507 inches nominal grip length, 1.000 inches nominal head length, 0.311 inches minimum and 0.320 inches maximum material accommodated thickness

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Grip Length: 0.507 inches nominal
Head Length: 1.000 inches nominal
Turnlock Stud Shank Style: stud shank
Turnlock Stud Head Style: fillister wing
Material Accommodated Thickness: 0.311 inches minimum and 0.320 inches maximum
Stud Head Height: 0.625 inches nominal
Stud Shank Major Diameter: 0.266 inches nominal
Material: steel overall
Surface Treatment: cadmium overall

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
W98292-3-320	Turnlock Fastener Stud

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5325-00-282-1883?

The FSCG of the NSN 5325-00-282-1883 is 5325

Does the NSN 5325-00-282-1883 have a Schedule B code assigned?

Yes, the Schedule B code is 9607190000

Does NSN 5325-00-282-1883 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5325-00-282-1883 contain precious materials?

Precious metal content is unknown

Does NSN 5325-00-282-1883 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5325-00-282-1883 was assigned to the Federal Catalog?

It was assigned 63 years ago, on Tue, Jan 1, 1963
