6110-01-388-6583

Find complete technical information, availability, and procurement data for: 6110-01-388-6583
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 6110-01-388-6583 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Electric Wire, and Power and Distribution Equipment

Federal Supply Classification

6110 Electrical Control Equipment

National Stock Number

6110-01-388-6583

Item Name Code

31517

Assigment Date

04/05/1994 (32 years ago)

An item designed to expedite or simplify the connection of two or more electrical conductors without bringing them to a fixed point such as a binding post or terminal. It may have a separate tubular shaped piece of nonmetallic, flexible material designed to be slipped over the crimped first piece to seal the conductor joint through heat sealing.

50.0 amp size rating, full operating voltage characteristic, 180.0 volts nominal and 355.0 volts nominal ac voltage rating, 180.0 volts nominal and 355.0 volts nominal dc voltage rating, 50.0 direct current rating in amps

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Direct Current Rating In Amps: 50.0
Ac Voltage Rating: 180.0 volts nominal and 355.0 volts nominal
Dc Voltage Rating: 180.0 volts nominal and 355.0 volts nominal
Operating Voltage Characteristic: full
Amp Size Rating: 50.0

Replaces National Stock Numbers

Below is a list of NSNs that have been officially superseded by this NSN:

NSN	Name	Date
5945-01-186-0112	No Name Available	05/01/2013

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
24998.100 FIND 65	Magnetic Contactor
6938ED19-17B	Magnetic Contactor

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 6110-01-388-6583?

The FSCG of the NSN 6110-01-388-6583 is 6110

Does the NSN 6110-01-388-6583 have a Schedule B code assigned?

Yes, the Schedule B code is 8543909000

Does NSN 6110-01-388-6583 require demilitarization?

"commerce control list items (ccli) - mut to the point of scrap required outside the united states. Inside the united states, mut is required when the demil integrity code (ic) is "3" and mut is not required when the demic is "6" (note 8)"

Does NSN 6110-01-388-6583 contain precious materials?

Item does not contain precious metal.

Does NSN 6110-01-388-6583 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 6110-01-388-6583 was assigned to the Federal Catalog?

It was assigned 32 years ago, on Tue, Apr 5, 1994
