5306-01-054-4604

Find complete technical information, availability, and procurement data for: 5306-01-054-4604
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 5306-01-054-4604 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Hardware and Abrasives

Federal Supply Classification

5306 Bolts

National Stock Number

5306-01-054-4604

Item Name Code

15903

Assigment Date

01/21/1978 (48 years ago)

dished hexagon head style, 0.892 inches minimum and 0.922 inches maximum fastener length, 3a thread class, right-hand thread direction, 0.444 inches minimum and 0.494 inches maximum thread length

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Thread Class: 3a
Thread Direction: right-hand
Thread Length: 0.444 inches minimum and 0.494 inches maximum
Fastener Length: 0.892 inches minimum and 0.922 inches maximum
Head Style: dished hexagon
Head Height: 0.156 inches minimum and 0.171 inches maximum
Width Between Flats: 0.492 inches minimum and 0.502 inches maximum
Grip Diameter: 0.3110 inches minimum and 0.3120 inches maximum
Nominal Thread Diameter: 0.312 inches
Grip Length: 0.428 inches minimum and 0.448 inches maximum
Thread Quantity Per Inch: 24
Minimum Tensile Strength: 160000 pounds per square inch
Material: steel comp e4340 or steel comp 4340 or steel comp 8740 overall
Surface Treatment: cadmium and chromate overall
Surface Treatment Document And Classification: qq-p-416,type 2,class 3 fed spec single treatment response overall
Thread Series Designator: unjf

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
BACB30NE5-7	Shear Bolt

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 5306-01-054-4604?

The FSCG of the NSN 5306-01-054-4604 is 5306

Does the NSN 5306-01-054-4604 have a Schedule B code assigned?

Yes, the Schedule B code is 7318152000

Does NSN 5306-01-054-4604 require demilitarization?

Items subject to the export administration regulations (ear) in parts 730-774 of title 15, code of federal regulations (cfr) (ccli or ear99) and determined by dod to present a low risk when released out of dod control. No demil, mut, or end use certificate is required. May require an export licensefrom doc.

Does NSN 5306-01-054-4604 contain precious materials?

Precious metal content is unknown

Does NSN 5306-01-054-4604 contain hazardous materials?

Indicates there is no data in the hmirs and the nsn is in a fsc not generally suspected of containing hazardous materials.

When the NSN 5306-01-054-4604 was assigned to the Federal Catalog?

It was assigned 48 years ago, on Sat, Jan 21, 1978
