1560-01-555-0151

Find complete technical information, availability, and procurement data for: 1560-01-555-0151
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 1560-01-555-0151 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Aerospace Craft and Structural Components

Federal Supply Classification

1560 Airframe Structural Components

National Stock Number

1560-01-555-0151

Item Name Code

31495

Assigment Date

08/27/2007 (18 years ago)

An assembly of wire cables fitted to runners, guides, levers and the like to remotely operate controls.

kc-135 stratotanker aircraft mission design series, 0.063 inches nominal material thickness, 3.000 inches nominal overall length, plate part name assigned by controlling agency, 1.000 inches nominal overall width

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Overall Length: 3.000 inches nominal
Overall Width: 1.000 inches nominal
Material Thickness: 0.063 inches nominal
Part Name Assigned By Controlling Agency: plate
Aircraft Mission Design Series: kc-135 stratotanker
Special Features: aisi 301 steel sh spec mil-s-5059 comp 301 sur cond 2b 1/2 hard f-12.35 finish after assembly f-1.10 finish f-12.46 on installation
Material: steel comp 301

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
5-86892-90	Aircraft Structural Plate

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 1560-01-555-0151?

The FSCG of the NSN 1560-01-555-0151 is 1560

Does the NSN 1560-01-555-0151 have a Schedule B code assigned?

Yes, the Schedule B code is 8803909060

Does NSN 1560-01-555-0151 require demilitarization?

"commerce control list items (ccli) - mut to the point of scrap required outside the united states. Inside the united states, mut is required when the demil integrity code (ic) is "3" and mut is not required when the demic is "6" (note 8)"

Does NSN 1560-01-555-0151 contain precious materials?

Item does not contain precious metal.

Does NSN 1560-01-555-0151 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 1560-01-555-0151 was assigned to the Federal Catalog?

It was assigned 18 years ago, on Mon, Aug 27, 2007
