1560-01-555-0144

Find complete technical information, availability, and procurement data for: 1560-01-555-0144
DODParts.com distributes related products varnishes dopes paints, aircraft parts and consumables, electrical parts, fittings and other components for the aerospace and defense industries. Submit the short price quote form for NSN 1560-01-555-0144 to receive an up to date pricing and availability quote by email.

Federal Supply Group

Aerospace Craft and Structural Components

Federal Supply Classification

1560 Airframe Structural Components

National Stock Number

1560-01-555-0144

Item Name Code

41028

Assigment Date

08/27/2007 (18 years ago)

A light, secondary structural member that does not completely partition various components such as the fuselage, boom, wing, and the like. It is designed to give cross-sectional shape and strength to the item of which it is a part.

4.000 inches nominal overall width, f-16 end item identification, spar part name assigned by controlling agency, 119.000 inches nominal overall length, 1.750 inches nominal material thickness

Product Characteristics

Below you’ll find the complete technical specifications and performance data for this part, including material details and compliance information.

Overall Length: 119.000 inches nominal
Overall Width: 4.000 inches nominal
Material Thickness: 1.750 inches nominal
End Item Identification: f-16
Part Name Assigned By Controlling Agency: spar
Aircraft Location: wing box-no. 10
Aircraft Mission Design Series: f-16
Special Features: dim are stocksize matl; c/o 1(-15 spar), plate; t7351
Material: aluminum alloy 7475
Material Document And Classification: fms-3004 mfr ref single material response

Related Parts

This NSN group includes multiple components designed to meet specific performance and operational standards. Each listing provides detailed specs, functionality data, and replacement compatibility information:

Part Number	Name
16W140-17	Aircraft Spar

FAQs

Find helpful answers about installation, operation, maintenance, compliance, and troubleshooting.

What is the FSCG of the NSN 1560-01-555-0144?

The FSCG of the NSN 1560-01-555-0144 is 1560

Does the NSN 1560-01-555-0144 have a Schedule B code assigned?

Yes, the Schedule B code is 8803909060

Does NSN 1560-01-555-0144 require demilitarization?

"commerce control list items (ccli) - mut to the point of scrap required outside the united states. Inside the united states, mut is required when the demil integrity code (ic) is "3" and mut is not required when the demic is "6" (note 8)"

Does NSN 1560-01-555-0144 contain precious materials?

Item does not contain precious metal.

Does NSN 1560-01-555-0144 contain hazardous materials?

Indicates there is no information in the hmirs. The nsn is in a fsc in table ii of fed std 313 and a msds may be required by the user. The requirement for a msds is dependent on a hazard determination of the supplier or the intended end use of item.

When the NSN 1560-01-555-0144 was assigned to the Federal Catalog?

It was assigned 18 years ago, on Mon, Aug 27, 2007
